Sliding table precision panel saw machine industrial wood saws

Configuration:
1. 3000*410mm Altendorf type sliding table.
2. tilt 0-45 degree.
3. electric up and down of main saw blade.
4. digital display of main saw blade tilting degree.
5. one set of Freud saw blade.
6. wooden case package.
7.  some easy broken parts( bearing / button / belt,etc).
Applications:
1. Apply to processing all kinds of density boards, shaving boards, wood-based panels, ABS panels, PVC panels, organic glass plates and solid wood and others with wood structure and similar hardness.

2. Movable table guide track is plating chromium steel balls structure, exact and durable.

3. Made of high-strengh extruded aluminum alloy,movable table is high in strength and won't bend.
4. With oxidation treatment, movable table surface is beautiful and hardwearing.

Model MJ-45-3000
 Sliding table size  3000*410mm
 Gross cut capacity  3000mm,have 2800mm,3200mm,3800mm for option,also can be customized
 Width between saw blade&rip fence  1250mm
 Saw blade diameter  300(250-350)mm
 Height of cut (300mm)  70-80mm
 Main saw spindle Speed  4500/6000rpm
 Main spindle diameter  30mm
 Tilting saw blade  0-45-90°
 Main motor Power  5.5kw
 Scoring motor power  1.1kw
 Scoring saw blade diameter  120mm
 Scoring saw blade speed  8000rpm
 Scoring saw diameter   20mm
 Weight  900kgs
 Machine body Package size       2200*1150*1100mm
 Sliding table Pack size  3350*480*320mm


Samples:

Video:
